CONSTRUCTION WINCH
Availability: In Stock
Deskripsi
CONSTRUCTION WINCH
Spesifikasi
| Capacity (t) | 2 | 3 | 5 | 6.3 |
|---|---|---|---|---|
| Max.Lifting Speed (m/min) | JM 1~10 JK 2~20 | JM 1~10 JK 2~20 | JM 0.8-8 JK 1.6-16 | JM 0.8-8 JK 1.6-16 |
| Max.Wire Rope Capacity (m) | 160 | 180 | 200 | 200 |
| Work Duty | M4/1Am | M4/1Am | M4/1Am | M4/1Am |
| Wire Rope Diameter (mm) | φ12 | φ16 | φ20 | φ22 |
| Drum Diameter (mm) | φ273 | φ325 | φ402 | φ425 |
| Motor Model | JM YZP132M1-6 JK YZP160M-6 | JM YZP132M2-6 JK YZP160L-6 | JM YZP160M-6 JK YZP180L-6 | JM YZP160L-6 JK YZP200L-6 |
| Motor Power | JM 4 JK 7.5 | JM 5.5 JK 11 | JM 7.5 JK 15 | JM 11 JK 22 |
| Capacity (t) | 8 | 10 | 12.5 | 16 |
|---|---|---|---|---|
| Max.Lifting Speed (m/min) | JM 0.8-8 JK 1.6-16 | JM 0.8-8 JK 1.6-16 | JM 0.8-8 JK 1.6-16 | JM 0.8-8 JK 1.6-16 |
| Max.Wire Rope Capacity (m) | 200 | 300 | 300 | 300 |
| Work Duty | M4/1Am | M4/1Am | M4/1Am | M4/1Am |
| Wire Rope Diameter (mm) | φ24 | φ26 | φ30 | φ34 |
| Drum Diameter (mm) | φ500 | φ560 | φ630 | φ680 |
| Motor Model | JM YZP160L-6 JK YZP200L-6 | JM YZP180L-6 JK YZP225M-6 | JM YZP200L-6 JK YZP250M1-6 | JM YZP200L-6 JK YZP250M2-6 |
| Motor Power | JM 11 JK 22 | JM 15 JK 30 | JM 22 JK 37 | JM 22 JK 45 |
